General data Type Ultrasonic through beam sensors Repeat accuracy < 0.2 mm Response time / release time 0.25 ms Belt speed 4 m/sec Min. label gap > 2 mm Label thickness < 5.9 mm Sensitivity adjustment Teach-in button IO-Link Output indicator LED yellow Communication interface IO-Link Yes Interface IO-Link V1.1 Baud rate 38,4 kBaud (COM 2) Electrical data Voltage supply range +Vs 18 … 35 VDC Current consumption max. (no load) 40 mA Electrical data Output function NO / NC adjustable Output circuit IO-Link / push-pull Output current < 100 mA Short circuit protection Yes Reverse polarity protection Yes Mechanical data Width / diameter 90 mm Fork width Sb 6 mm Height / length 45 mm Penetration depth 70 mm Depth 18 mm Type U profile Housing material Aluminum anodized Connection types Connector M12 5 pin Ambient conditions Operating temperature 0 … +60 °C Protection class IP 67
